Solo Acoustic Stage Plot Template

Start from a finished solo acoustic stage plot for one performer using vocal mic, acoustic guitar DI, a compact monitor position, and a simple input list.

Build a solo acoustic stage plot

Example PDF

Example PDF from this template

Actual RigFlow PDF export showing the vocal mic, acoustic guitar DI, power, and monitor position for a solo acoustic setup.

Actual RigFlow PDF export generated from the Solo acoustic stage plot template — Actual RigFlow PDF export showing the vocal mic, acoustic guitar DI, power, and monitor position for a solo acoustic setup.

Build a solo acoustic stage plot

Best fit for this template

Best for singer-songwriters, acoustic guitar plus vocal sets, cafe stages, opening slots, and small venues with fast changeovers.

The PDF should let the venue confirm performer position, vocal input, guitar DI, power, and monitor needs without another setup email.

Venue questions this template answers

Can the venue prepare a vocal microphone, boom stand, and DI?
Is passive DI, active DI, or the performer’s preamp preferred for the guitar?
Can one monitor mix carry both vocal and guitar clearly?

Layout priorities

Draw the stage from the audience perspective.
Place the vocal microphone in front of the performer and leave room for guitar movement.
Keep the DI and power close to the performer so cable paths stay short.

Example stage layout

Place the performer at center stage with the vocal mic downstage and the guitar DI beside the performer.
Place one wedge in front, angled away from the vocal microphone to reduce feedback.

Suggested input list

Vocal microphone
Acoustic guitar DI
Optional playback stereo L/R

Equipment notes

State whether the guitar output comes from the pickup, a preamp, or a pedalboard.
List the DI, boom stand, and vocal microphone the venue should prepare.
Mark power for tuner, preamp, or pedalboard near the performer.

Monitor notes

One wedge in front of the performer is usually enough.
Write whether the performer needs more vocal, more guitar, or a balanced mix.
If in-ear monitors are used, note that the house wedge is not needed.

Common missing details

Not saying whether the acoustic guitar is DI or mic only.
Forgetting the vocal and guitar balance needed in the monitor.
Leaving the power need for a tuner, preamp, or pedalboard out of the stage plot.

PDF review checklist

Vocal mic, guitar DI, power, and monitor are each visible as separate needs.
Audience perspective and performer position are clear.
Venue-provided items and performer-owned gear are not mixed together.
